3D Laser TRUMPF TRUMATIC L 4030
3D Laser TRUMPF TRUMATIC L 4030 was manufactured by the machine manufacturer TRUMPF. Machine TRUMPF TRUMATIC L 4030 was built in 2002 year.
General data | |
|---|---|
| Location | Czech Republic |
| region | Jihomoravský kraj |
| Year of manufacture | 2002 |
| Warranty | Without warranty |
| Technical condition | Good |
| Payment | Before receipt |
| Transport | The seller organizes the transport at a surcharge |
| Status | A test can be performed |
| Stock number | 3083 |
Technical parameters | |
|---|---|
| Laser power | 4000 kW |
| Maximum workpieces length | 4000 mm |
| Maximum workpieces width | 2000 mm |
| Number of heads with lasers | 2 pcs |
| Maximum thickness of the cut sheet metal (Normal Steel) | 15 mm |
| Maximum thickness of the cut sheet metal (Stainless Steel) | 25 mm |
| Maximum thickness of the cut sheet metal (Aluminum) | 10 mm |
| Machine height | 2000 mm |
| Machine length | 11500 mm |
| Machine width | 6000 mm |
| Machine weight | 16 t |
Equipment | |
|---|---|
| CNC control | |
