Technical parameters |
|---|
| Clamping force |
356.9 t |
| Injection weight |
1133 g |
| Minimum distance between the plates for mounting the mold |
350 mm |
| Maximum distance between the plates for mounting the mold |
700 mm |
| Height of the plate for mounting the mold |
1070 mm |
| Width of the plate for mounting the mold |
1020 mm |
| Distance between the columns (horizontal) |
710 mm |
| Distance between the columns (vertical) |
660 mm |
| Length of the ejector stroke |
180 mm |
| Screw diameter |
70 mm |
| Total power demand |
70 kW |
| Machine length |
7300 mm |
| Machine width |
1600 mm |
| Machine height |
2100 mm |
| Weight of the injection molding machine |
17 t |
