Technical parameters |
|---|
| Length of the working table |
365 mm |
| Width of the working table |
150 mm |
| Maximum height of the grinded workpieces (for a new grinding wheel) |
350 mm |
| Maximum rotary speed of the spindle |
3000 1/min |
| Maximum distance from the table to the spindle axis |
400 mm |
| Diameter of a new grinding wheel |
180 mm |
| Maximum diameter of a grinding wheel |
13 mm |
| Diameter hole in the grinding wheel |
31.8 mm |
| Total power demand |
0.4 kW |
| Maximum length of grinding (without the grinding wheel output) X-axis |
375 mm |
| Maximum width of grinding (without the grinding wheel output) Y-axis |
175 mm |
| Machine height |
1760 mm |
| Machine length |
1200 mm |
| Machine width |
950 mm |
| Machine weight |
0.4 t |
